Specifications
Model:KGS 254 Plus
Dimensions L x W x H: 930 x 690 x 590 mm
Support surface: 1.000 / 505 x 365 mm
Maximum cutting width: 90°/45°: 305 mm/214 mm
Maximum cutting depth: 90°/45°: 90 mm/54 mm
Maximum cross-section of the workpiece
– Straight cut: 90°/90° 305 x 90 mm
– Double mitre: 45°/45° 214 x 54 mm
Idle revolution: 3.900 – 5.150 /min
Revolutions at rated load: 5.150 /min
Cutting speed: 68,5 m/s
Saw blade Ř: 254 x 30 mm
Turntable setting left/right: 47 °/60 °
Saw blade tilt left/right: 46 °/46 °
Rated input power: 2 kW
Weight: 24 kg

Features & Benefits
Superb dust extraction capability thanks to a dual port design mounted close to the work piece.
Vario-Constamatic (VC) full-wave electronics for infinitely variable speed change. Under load the speed remains almost constant.
Metabo “Quick” saw blade change without key
Also suitable for sawing non-ferrous metals
All control elements can be operated from the working position with sliding function for wide work pieces.
Motor soft start for long tool life
Integrated cutting depth control
Transport lock
Saw head can be inclined on both sides
Saw blade stop for easy saw blade change

(3 Year Warranty)
Metabo power tools have a particularly long service life.
As they rarely require repairs, Metabo has developed an additional warranty for you – the XXL warranty. If you register, the normal 1 year warranty is extended to 3 years.
Registration is only possible within 4 weeks of the purcha

Specifications
Model:KS 216 M
Dimensions L x W x H: 480 x 543 x 325 mm
Maximum cutting width 90°/45°: 120 mm/80 mm
Maximum cutting depth at 90°/45°: 60 mm/45 mm
Maximum cross-section of the workpiece:
– Straight cut 90°/90°: 120 x 60 mm
– Double mitre 45°/45°: 80 x 45 mm
Turntable setting left/right: 47 °/47 °
Saw blade tilt left/right: 45 °/0 °
Saw blade: Ř 216 x 30 mm
Rated input power: 1,35 kW
Idle revolution: 5.000 /min
Revolutions at rated load: 3.450 /min
Cutting speed: 39 m/s
Weight: 9 kg
Cable length: 2 m

Features & Benefits
Compact light-weight with ergonomically designed carry handles, ideal for mobile use
For sawing wood, coated panels and slats
Easy transport by means of saw head lock
Aluminium die-cast parts for low weight, long service life and precision
Fast and precise setting of common angles using stop points
Laser for exact display of the cutting line (mains powered, no batteries required)
Freely adjustable table extension on both sides with a practical support surface and integrated crosscut fence
Integrated work light for illumination of the cutting line (mains powered, no batteries required)
High sliding rear fence profiles for safe sawing
Material clamp for secure fixing of the work piece from the top or front

Accessories
Carbide saw blade (40 teeth)
2 table length extensions
Material clamp
Tool for saw blade change
Dust extraction adapter 0910059955
Chip collection bags
Laser

(3 Year Warranty)
Metabo power
